MAX OUTPUT POWER
EIA AT 1kHz AND 1% THD
8Ω PER CHANNEL 400 W
4Ω PER CHANNEL 720 W
2Ω PER CHANNEL 1190 W
8Ω BRIDGED 1400 W
DISTORTION
THD 20Hz – 20kHz AND 1W TO FULL POWER  0.08%
THD AT 1kHz 1dB BELOW CLIP  0.1%
SIGNAL + NOISE/NOISE RATIO  >-100dB 20Hz-20kHz
CHANNEL SEPARATION @ 10kHz >65dB
OUTPUT IMPEDANCE 22 mΩ
SLEW RATE 70 V/μs
INPUT SENSITIVITY  Selectable 0.775mV (36dB gain) or 1.23V (32dB gain)
INPUT IMPEDANCE  20kΩ differential, 10kΩ single ended
FREQUENCY RESPONSE  7kHz-46kHz +0dB / -3dB
FREQUENCY BANDWIDTH  10kHz-40kHz +0dB / -0.5dB
FRONT PANEL

GAIN CONTROLS 2 x Rotary Control
INDICATORS: POWER ON  Red LED
INDICATORS: SIGNAL LEVEL  Green LED
INDICATORS: -3dB Yellow LED
INDICATORS: LIMIT Red LED
INDICATORS: BRIDGE Yellow LED
INDICATORS: THERMAL Red LED
INDICATORS: CARD ENABLE Green LED
REAR PANEL
INPUT CONNECTORS XLR-female
LINK CONNECTOR  XLR-male
OUTPUT CONNECTOR  3 x 4 pole Speakon
POWER 230V Setting  115V Setting
OPERATION VOLTAGE 180-250V 90-125V
SOFT START Yes Yes
PEAK INRUSH CURRENT 11.8 A 23A
MIN START VOLTAGE  140V 70V
CURRENT DRAW AT 4Ω 230V Setting  115V Setting
QUIESCENT POWER (NO LOAD) 0.9 A rms 1.8 A rms
1/8 OF FULL POWER (-9dB) 4.8 A rms 9.6 A rms
1/3 OF FULL POWER (-5dB) 7.2 A rms 14 A rms
DIMENSIONS
WIDTH 483mm (19ins)
HEIGHT 88mm (3.5ins) 2U
DEPTH (incl. handles) 385mm (15.2ins)
WEIGHT 9.5kg (20.9lbs)
